eABG 4820
Tracked Paver / e-Drive
About this machine
Emission-free paving, with the capacity of a diesel machine.
Sustainable and productive on every project.
The eABG 4820 combines the sustainability of a fully electric drive with the production capacity of a conventional paver. The machine itself produces zero emissions, and measured across the entire chain its CO2 emissions are around 70% lower than those of a comparable diesel machine. Ideal for urban projects, low-emission zones and sites where noise and emissions matter.
The Penta high-voltage system with a 270 kWh traction battery delivers 99 kW of power, enough to run a full working day. The eABG 4820 has already proven what it can do: it set a record for the most tonnes of asphalt laid in a single day by an electric paver.
Just like the diesel ABG 4820, the machine features robust tracks, four individual hydrostatic drives for the conveyors and augers, and the proven Variomatic screeds (VB 78, VB 79 and VB 88 ETC).
Specs
Penta high-voltage system, 270 kWh traction battery
Electric motor (PMSM), 99 kW
600 V electrical system
Electronic drive
Lifetime-lubricated track support rollers
Forged and hardened track links
Automatic track tensioner
Bolted rubber pads
Large truck push rollers (160 mm)
Four individual hydrostatic drives for conveyors and augers
Compatible with Variomatic VB 78, VB 79 and VB 88 ETC screeds
(Optional) Individually controlled hopper wings
(Optional) Hydraulic hopper front flap
(Optional) Reversible conveyor
(Optional) Hydraulic auger height adjustment
(Optional) Ultrasonic auger control
(Optional) Central lubrication
(Optional) Light push rollers (110 mm)
(Optional) Protective half shells
